Leaps Prep Preparative Liquid Chromatography System
Simple and flexible preparative purification
A truly fully automatic preparative system, from automatic sampling to automatic fraction collection, from operation control to analysis.
Leaps Prep Preparative Liquid Chromatography System
Autosampler：A30
Column Oven：C10\C12
Fraction Collector：F10
UV-Vis Detector:D10
Liquid Delivery Pump：MP10\MP22
Preparative "Core" Power, Empowering Product Purification
Infusion System Designed for High-Pressure Preparative Chromatography
- Flow range up to 0–150 mL/min
- Pressure range: 0–400 bar (@ 0–50 mL/min)
- Supports up to four solvents for greater flexibility across a wide range of applications.
Automatic Fraction Collection System
- Automatic sampling and automatic fraction collection.
- Automatic collection judgment based on peak threshold, slope and area.
- Multiple sample rack sizes available (30mm, 16mm, 13mm).
Large-volume injection and stable separation.
- Supports various injection modes including 5 mL large-volume injection.
- Flexible sample tray options, compatible with 2 / 5 / 7 mL sample vials.
- Sample compartment with optional cooling function.
- Supports upgrade to two-dimensional preparative HPLC system.
Efficient Separation and Column Switching Functionality
- High-capacity column oven, supports 50 mm ID preparative chromatography columns.
- Efficient separation with loading capacity from mg to gram level.
- Forced air circulation design ensures a more uniform temperature field.
- Optional dual-valve switching enables automatic desalination and purification with dual columns.
